3-Point PTO Stump Grinder & 2-Ton Heavy-Duty Dump Trailer Combo, SG24 & DT4X8
3-Point PTO Stump Grinder
| Flywheel Diameter | 24 in | Mounting | 3 Point Hitch Cat. 1 (Quick Attach Compatible) |
| Flywheel Thickness | 3/4 in | PTO Input | 540 RPM |
| Carbid Tip | 34 PCS | Max. Torque | 1200 N·m |
| Carbid Tip Material | YG11C | PTO Shaft Weight | 44 LBS |
| Tip Holder Material | 42CrMo | Dimensions | 29 × 37 × 38 in |
| PTO HP Required | 15–45 HP | Packing | Iron Frame + Carton |
| PTO Shaft (Included Shipping) | 1-3/8” 6 Spline Tractor and Implement Ends PTO Driveline Shaft with Slip Clutch | Weight (N.W/G.W.) | 450/563 LBS |
| Friction Torque Limiter (Slip Clutch) | Included |
2-Ton Heavy-Duty Dump Trailer
| Capacity | 37.5 cu.ft. |
| Dump | Rear |
| Axle | Tandem |
| Tire Size | 20x10-8 |
| NO.Of Tires | 4 |
| Weight | 750 lbs |
| Bed Width | 47 in |
| Bed Height | 27 in |
| Bed Length | 92 in |
| Bed Floor | T1.5 |
| 0verall Width | 50 in |
| 0verall Height | 42 in |
| Overall Length | 136 in |
| Dump Angle | 45° |
| Panel Height | 15 in |
| Tongue Jack | STD. |
| Packing Size | 53x21x98.5 in |
| Weight (N.W./G.W.) | 831/1018 lbs |
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
